Product Description
two-year warranty for this item!!!
Here is the manual
If you have any other problems,please feel free to contact us,we will gland to help you.
IHSS57-36-10 | IHSS57-36-20 | |
control mode | Pulse+direction | |
Holding Torque | 1NM | 2NM |
Type | Integrate Closed Loop Stepper Motor+Drive | |
rated operational voltage | 36V | 36V 5A |
Phase | 2ph | 2ph |
Current / Phase | 2.8 |
|
Step Angle(degrees) | 1.8 | 1.8 |
Resistance | 0.4ohms |
|
Inductance | 1.2mh |
|
Detent Torque | 400gcm |
|
Lead line number | 4 |
|
Main features | no step to lose | |
Main features
1.No Mis-Step
2.Low Heat / High Efficiency
3.Smooth and Accurate
5.High Torque / High Speed
